Nokia Lumia 510 Charging Ways Repair Solution

Nokia Lumia 510 is its charging problem, and this is mainly because if your charging connector is giving you problems then sooner or later your phone is going to be out of charge hence rendering you completely helpless, therefore it is highly recommended that one should get it fixed as soon as one notices any such charging issues.

In the following lines you will get to know about some of the charging problems related to Lumia 510 along with their solution.

Problem

  • Nokia Lumia 510 is not charging at all.
  • Phone charges really very slow.
  • Lumia 510 heats up during charging.
  • Phone does not give any response when charger is connected.

Reasons of Problems

  • Phone could be water damaged.
  • Dust particles might be present in charging connector.
  • Your Nokia Lumia 510 charger might be faulty.
  • Connection in the phone might be broken.
  • Phone is encountered any physical damage.
  • Any of the capacitors might be faulty.
  • Charging IC might be faulty.

Workaround

  • If the charging is slow then all you have to do is to check with any other Nokia Lumia 510 charger, but you have to make sure that the charger is original, as slow charging issues almost always occurs with phones using 3rd party chargers.
  • Clean battery charging pins and check.
  • Clean charging connector pins.

Tools Required

Following are the tools you need before you plan to go with hardware method
  • Soldering Gun.
  • Heat Gun.
  • Multi meter.
  • Plastic separation tool.
  • Screw driver.
  • Jumper Wire (Copper wire).

Hardware Solution Nokia Lumia 510 Charging Problem

  • The very first thing that you need to do is to check voltage at the testing point 1 (as mentioned above in Figure). The voltage should be around 4.9V to 5V. other testing points are for USB connector.
  • After removing body of your Lumia 510, the very first thing that you need to do is to re-solder first pin of charging connector and check.
  • Check the fuse and diode for possible open and short circuit.
  • If same problem Check Charging connector ways marked in below image.
Nokia Lumia 510 Charging Problem ways Solution
  • If any Charging ways is missing then make a jumper with the help of Jumper Wire.
  • If all Charging track ways is working means then replace Charging Connector. Your problem will solved.
If you have further Questions please leave a comment.
Note: Please note that even though every solution posted on our website is tested by one or more members of our team before posting, but still we do not take any responsibility for any damage it may cause to your cell phones. Use these repairing solutions at your own risk. Thank You.

How to Solve Sony Hazel J20i handsfree Jack Problem?

Here's the solution for Sony Hazel J20i in fixing handsfree problem. If something went wrong like if there is no sounds can be heard if the handsfree or loudspeaker is being activated, this solution might help for your repair.

Sony J20i handsfree Problems

  • Low sound in earphone.
  • No Sound.
  • Distorted sound.
  • Unbalanced sound.

Sony Hazel J20i Workaround

  • Check Volume Level.
  • Check with any other working earphone.
  • Update your OS

Hardware for Sony Hazel J20i Handsfree Problem

  • Clean and re-solder Charging connector as well as on-board connector.
  • If same problem Replace the charging connector and check.
  • If the problem continuous then replace the Diode V2417.
  • If same problem the last and final step Re-hot or Replace N2422 IC.
sony-hazel-j20i-handsfree-jack-problem-solution

If you have further Questions please leave a comment.
Note: Please note that even though every solution posted on our website is tested by one or more members of our team before posting, but still we do not take any responsibility for any damage it may cause to your cell phones. Use these repairing solutions at your own risk. Thank You.

Nokia 603 Power On/Off Switch ways Repair Solution

Here's a solution for Nokia 603 power ON OFF switch when damaged or being lifted.
If the Nokia 603 shows charging indication when the battery charger is being plug-in but unable to switch on when pressing the power switch button, this solution might possibly help fix and solved the problem.

In the following lines you will get to know about Nokia 603 power button problems as well as their solutions:

Nokia 603 On/Off Switch Problems

  • Nokia 603 power button becomes stiff.
  • Power button becomes unresponsive.

Nokia 603 Power Switch Workaround

For Nokia 603 power button problem there is no work around method, however you can try using a pin and move it all around the nokia 603 power button, as this might be able to take away some stiffness from your power button.

Hardware Solution for Nokia 603 On/Off switch

  • The first thing you need to test is there any water damage or dust.
  • if any thing just clean it with the help of IPA or any cleaning liquid.
  • If same problem then check the Track ways of Nokia 603 power on/off switch. Marked in below image.
  • If any of the track is missing make a jumper with the help of jumper wire.
nokia-603-on-off-switch-problem-solution

If you have further Questions please leave a comment.
Note: Please note that even though every solution posted on our website is tested by one or more members of our team before posting, but still we do not take any responsibility for any damage it may cause to your cell phones. Use these repairing solutions at your own risk. Thank You.

Samsung C3312 / C3310 Insert Sim Repair Solution

Hardware method to solve Samsung C3312 or C3310 InsertSim Problem. which is known to be one of the most successful phone of Samsung. Normally Samsung C3312 doesn’t encounter much problem, but if it does there is always a solution. check our C3312 Speaker solution also.

C3312 Insert Sim Problems

  • Insert SIM card error.
  • Phone book inaccessible.

Tools

  • Jumper wire.
  • Soldering Gun.
  • Heat Gun / Heat Blower.
  • Multi-meter.

Workaround

  • Restart your phone.
  • Remove, clean and re-insert your SIM card.
  • Check with any other SIM card.

Reasons for C3312 Insertsim Problems

  • It might be due to dust on SIM Jacket contacts.
  • SIM power line might be faulty, if it happens then it doesn’t show SIM card.
  • It might be due to faulty capacitors. They are total 4 in numbers, if any one of them is faulty then it will affect your overall SIM card function.
  • Issue might also be due to SIM card IC.

Hardware Procedure to solve Samsung C3312 Insert Sim Problem

  • Check the SIM card pin connectors for possible damaged, replace if necessary.
  • Clean the SIM card pin connectors if oxidation build up spotted. (corrosion may also cause insert SIM issues)
  • Check and trace the sim card track ways marked in below image with the help of a multi-meter, if any of them is faulty make a jumper.
Samsung-C3312-C3310-InsertSim-Problem-Solution

If you have further Questions please leave a comment.
Note: Please note that even though every solution posted on our website is tested by one or more members of our team before posting, but still we do not take any responsibility for any damage it may cause to your cell phones. Use these repairing solutions at your own risk. Thank You.

Sony Ericsson Xperia X10i Memory Card Ways Solution

This solution covers for hardware level of repair for SonyEricsson Xperia X10i Memory Card Problem and Also you will find Sony Xperia X10i Memory Card Ways and Jumpers information in the diagrams further in this article.

Problem

  • Memory Card not found.
  • Not able to store data in MMC.
  • MMC not accessible.
  • Not able to read MMC.

Manual Solution

  • Remove and reinsert memory card and check.
  • Go into settings and check memory card status.
  • Check with any other good memory card and check.
  • Scan memory card for viruses from your PC and check.
  • Verify proper action of memory card slot spring, as if it is damaged then your phone won’t read your memory card. In this case replace entire Memory card assembly.
  • If everything else fails then format your memory card.

Hardware Solution for Sony Xperia X10i Memory card problem

  • Pull up Xperia X10i memory card circuit contacts with the help of a pin to ensure that memory card socket contacts connect with memory card’s contacts.
  • Re-solder all the pins of memory card slot.
  • Re-solder on-board connector of MMC Card and check.
Sony-Ericsson-Xperia-X10i-Memory-Card-problem-Solution
  • Check above mentioned Memory card track ways. If you find any problem or broken any ways then apply jumper.
If you have further Questions please leave a comment.
Note: Please note that even though every solution posted on our website is tested by one or more members of our team before posting, but still we do not take any responsibility for any damage it may cause to your cell phones. Use these repairing solutions at your own risk. Thank You.

Samsung Champ Duos E2652 Charging Ways Solution

In case you are trying to solved Samsung E2652 with Charger error problem when the charger is plug-in this solution may possibly help for your troubleshooting.

Problems

  • Phone no charging.
  • Phone show's "PC Connection".
  • Battery heats up.

Reasons of Problems

  • Might be the problem in charger or charger’s pin.
  • It also happens due to the dust present in charging connector of your phone.
  • Dry soldering of charging pins, you need to re-solder them again. However for that you need to remove metal sheet over charging pins with the help of a heat gun in order to access charging pins for soldering.
  • Might be due to uneven voltage. It happens due to faulty circuit.
  • Fuse or Capacitor might also be faulty.

Workaround

It is always great that if workaround methods are able to resolve your charging problems, as none of us wants to go into the hardware of their phone.
  • Check with any other original Samsung charger.
  • Clean charging connector of your phone from outside and check.

Tools Required

Following are the tools you need before you plan to go with hardware method
  • Soldering Gun.
  • Heat Gun.
  • Multi meter.
  • Plastic separation tool.
  • Star screw driver.
  • Jumper Wire (Copper wire).

Hardware Solution for Samsung E2652 Charging Problem

  • Check and  replace the battery Charger.
  • Check and replace the phone's battery. A fully drained battery won't charge up.
  • Check/clean or replace the charging jack connector and the PCB pads.
  • Trace the charging Ways Marked in below image. If any of track ways is missing just make a jumper with jumper wire.
Samsung E2652 Charging Ways Problem Solution
  • If all Charging track ways is working means. Replace Q301 your problem will solve.
If you have further Questions please leave a comment.
Note: Please note that even though every solution posted on our website is tested by one or more members of our team before posting, but still we do not take any responsibility for any damage it may cause to your cell phones. Use these repairing solutions at your own risk. Thank You.

Sony Ericsson Xperia neo V MT11i Touch screen Repair Ways Solution

If you are looking and having trouble finding where to put a jumper if the touchscreen pin connector is already gone or lifted due to water water damaged on Sony Ericsson MT11i. This solution might help you to ease out your hard time finding where to solder a jumper wire on it just to fix a touchscreen not working problem.

Let’s have a look at Sony Ericsson MT11i touch screen problem and its step by step solution.

Problems

  • Touch not responding
  • Slow Response.

Manual Solution

Here is the manual solution of Sony Ericsson MT11i touch screen problem:
  • Restart your Sony Ericsson MT11i and Check.
  • Factory Reset your phone (Make sure to Backup your entire data)

Hardware Solution

Here is the hardware solution of Sony Ericsson MT11i touch screen problem:
  • Unplug and plug touch screen strip and check.
  • Plug-in any other good Touch Screen and Check. This step is to verify whether the problem is in hardware or Sony Ericsson MT11i touch screen is faulty.
  • If the problem is in hardware then clean touch on board connector and check.
  • Gently heat surrounding components of touch screen and check.
  • Re-solder each pin of touch connector and check.
  • If same problem check Touch screen track ways marked in below image
Sony Ericsson MT11i Touch screen ways Problem Solution
  • If any Track ways is missing make a jumper with jumper wire.
  • If all track ways is working fine but touch screen is not working. This is the last and finnal step is Re-hot the red marked IC gently. Your problem will solved.
  • All the above methods will surely solve your problem, but make sure that you check the status of your Touch Screen after every step you perform, as it might be able to solve that problem.
If you have further Questions please leave a comment.
